> Adopts 8MP/5MP progressive CMOS, provides 8MP 30FPS/5MP 50FPS Stream.
> 140dB WDR, 0.0001Lux min. illumination.
> F1.0, 2.8mm/3.6mm lens optional.
> No LED, visual 50m
> PoE&DC12V.
> Built-in waterproof high quality microphone (-32dB).
> Built-in micro SD slot for local recording, supporting Max. 256GB.
> Built-in hardware reset.
> Audio 1in/1out, alarm 1in/1out.
> IP67&IK10, -50°C ~65°C working temperature.
> Customizable Video Analysis Based on AI ISP, with Highest Accuracy:
Enabled AI Package as default: Face Recognition, Human/Face/Vehicle Detection, People Counting/Opposite Direction Detection, Smart Motion Detection/Linecrossing Detection/Intrusion Detection.
Customized based on detailed requirements: License Plate Recognition, Special Object Recognition such as birds, Fall Down Detection, Fire and Smoke Detection, Abnormal Video Detection, Abnormal Audio Detection, Motor Vehicle Detection, Non-Motor Vehicle Detection.
Model | IPC-MGA-8800 | IPC-MGA-8500 |
Camera | ||
Main Solution | SSC379G+IMX678 | SSC379G+SC450AI |
Image Sensor CMOS | 1/1.8’’ 8Megapixel | 1/1.8’’ 5Megapixel |
Effective Pixels | 3840*2160 | 2592*1944 |
Min. Illumination | 0.0001Lux @ (F1.2, AGC ON) | |
Shutter | 1/2s-1/50,000s | |
Lens | F1.0, 2.8mm/3.6mm lens optional | |
Day&Night | Always colorful image even in quite low lux. conditions | |
DNR | 3D Digital Noise Reduction | |
WDR | Yes, real WDR 140dB | |
Compression Standard | ||
Codec | H.265+/H.264+/H.265/H.264/MJPEG. | |
Data Rate -Main | 256-16000kbps | 256-12000kbps |
Data Rate -Sub | 50-2048kbps | 50-2048kbps |
Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | |
Audio Record | Yes | |
Image | ||
Max. Resolution | 8MP(3840*2160) | 5MP(2592*1944) |
Frame Rate | 30FPS | 50FPS |
Features | DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking | |
Image Adjustment | Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. | |
Network | ||
Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; | |
Compatibility | ONVIF (Profile S/Profile G/ Profile T); CGI; | |
HIKVISION/Dahua/XM; | ||
RTMP, RTSP, NFS, VoIP, TS streaming | ||
HTTP Streaming/HTTP Notification | ||
AI Features |
Customizable Video Analysis Based on AI ISP, with Highest Accuracy: Enabled AI Package as default: Face Recognition, Human/Face/Vehicle Detection, People Counting/Opposite Direction Detection, Smart Motion Detection/Linecrossing Detection/Intrusion Detection. |
|
Customized based on detailed requirements: License Plate Recognition, Special Object Recognition such as birds, Fall Down Detection, Fire and Smoke Detection, Abnormal Video Detection, Abnormal Audio Detection, Motor Vehicle Detection, Non-Motor Vehicle Detection. | ||
Interface | ||
Network | RJ-45 LAN Port | |
POE | Yes, Built-in POE | |
Audio | Built-in Microphone, line audio 1in/1out | |
Alarm | Alarm in/out | |
Local Recording | Built-in micro SD slot for local recording, supporting max. 256GB | |
Hardware Reset | Yes, Built-in reset button | |
General | ||
Color | White | |
Accessories | Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers | |
Power Supply | PoE&DC12V | |
Work Humidity | 10%-90% | |
Operation Temperature | -50℃-65℃ | |
Surge Protection | External/Built-in SPD | |
Proof | Metal; IP67&IK10; for both indoor & outdoor. | |
Power Consumption | Max. 17W | |
Size | 197.1*62.7*66.1mm | |
Weight | N.W.: 520g, G.W.: 620g | |
* We may adopt the backup solution when the main solution chipset is in shortage. | ||
We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. |
