> Adopts 2MP/5MP/8MP progressive CMOS, provides 2MP 30FPS/5MP 25FPS/8MP 20FPS Stream.
> WDR, 0.01 Lux min. illumination.
> 2.8mm/3.6mm fixed lens.
> 24pcs of SMD IR LEDs, IR distance 25m.
> WiFi&DC5V, power adaptor included in the package.
> Built-in microphone and speaker for two-way talk.
> Built-in micro SD slot for local recording.
> Look at your home at any time and from anywhere with remote live video streaming via mobile App.
> -10°C ~50°C working temperature.
> Smart Detection based on CV
Detection: Human/Vehicle Detection
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
Face Detction / Baby Crying detection / Pet Detection optional.
Model |
IPC-M1-1800 |
IPC-M1-1500 |
IPC-M1-1200 |
Camera |
|||
Main Solution |
T40N+SC8238 |
SSC377+GC4653 |
SSC377+GC2063 |
Image Sensor CMOS |
1/2.7’’ 8Megapixel |
1/3’’ 4Megapixel |
1/2.9’’ 2Megapixel |
Effective Pixels |
3840*2160 |
2560*1920 |
1920*1080 |
Min. Illumination |
0. 01Lux (F1.8, Color), 0 Lux (F1.8, IR ON) |
||
Shutter |
1/2s-1/50,000s |
||
Lens |
2.8mm/3.6mm fixed lens |
||
Day&Night |
ICR, Smart IR, Controllable IR LEDs |
||
DNR |
3D Digital Noise Reduction |
||
WDR |
Yes, digital WDR |
||
Compression Standard |
|||
Codec |
H.265/H.264/MJPEG |
||
Data Rate -Main |
256-16000kbps |
256-8000kbps |
256-8000kbps |
Data Rate -Sub |
50-1000kbps |
50-1000kbps |
50-1000kbps |
Audio Compression |
G.711A/G.711U/AAC/PCM/G.726 |
||
Audio Record |
Yes |
||
Image |
|||
Max. Resolution |
8MP(3840*2160) |
5MP(2560*1920) |
2MP(1920*1080) |
Frame Rate |
20FPS |
25FPS |
30FPS |
Features |
DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking |
||
Image Adjustment |
Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. |
||
Network |
|||
Protocols |
TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; |
||
Compatibility |
ONVIF (Profile S/Profile G/ Profile T); CGI; |
||
AI Features |
Smart Detection based on CV |
||
Interface |
|||
Network |
No RJ-45 LAN Port |
||
Wifi |
Yes, 2.4GHz single band as default, 2.4GHz&5GHz dual band optional |
||
Audio Input |
Built-in microphone |
||
Audio Output |
Built-in speaker |
||
Local Recording |
Built-in micro SD slot, supporting maximum 256GB |
||
Hardware Reset |
Yes |
||
General |
|||
Color |
White&Black |
||
Accessories |
Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers |
||
Power Supply |
USB DC5V, power adaptor included |
||
Work Humidity |
10%-90% |
||
Operation Temperature |
-30°C ~50°C |
||
Proof |
Plastic, IP66 water proof, Indoor&Outdoor |
||
Power Consumption |
Max. 5W |
||
Size |
86.49mm*75mm*96.6mm |
||
Weight |
N.W.: 300g, G.W.: 390g |
||
* We may adopt the backup solution when the main solution chipset is in shortage. |
